Eaton 9910-D3034 120KVA 400V UPS
- Brand: Eaton
- Category: 93HD Series
9910-D3034 – 120KVA (108KW), 400VAC, Transformer-based
R390,262,00 + VAT
Shipping alculated at checkout
Shipping
Major Cities (2-3 Days)
Regional (2-7 Days)
International (5-30 Days)
Support
About this item
- Model: 9910-D3034
- Rating: 120KVA
- Power Output: 108KW
- UPS Topology: SCR-based rectifier, IGBT-based inverter, battery connect with DC link
- Dimensions (W x D x H): 890 x 855 x 1900mm
- Weight: 960kg
- Degree of Protection: IP20
- Display: 7’’ HMI, 3 x LEDs for notice and alarm
- Communication Ports: 1x RS232 & RS485, with EPO button, 3 x dry contact (settable from LCD)
- Rated Input Voltage: 380/400/415VAC (Three Phase)
- Operating Frequency: 50 or 60Hz
- Input Power Factor: 6-pulse：≥0.8
- Rated Output Voltage: 380 Vac, three-phase, 3-wire+N+PE, (400, 415Vac selectable)
- Overload Capacity without Bypass: 110% load, continuous operating, 125% load, 10 minutes, 150% load, 1 minute
- Parallel Quantity: 8
- Efficiency (Full Load): 86%
- Automatic Bypass: Static Switch
- Battery Nominal Voltage: VRLA: 360V (180 cells), 372V186 cells, 384V (192 cells)
