Eaton 5PX2200iRT2UG2 2200VA 220V UPS

The Eaton 5PX2200iRT2UG2 is a 2200VA line-interactive uninterruptible power supply (UPS) designed for rack-mounted or tower configurations. It features a unity power factor (W=VA), delivering more real power to connected equipment. The UPS operates with high efficiency up to 98%, reducing energy consumption and cooling costs. Its Advanced Battery Management (ABM®) technology extends battery life by up to 50% and offers predictive maintenance capabilities. The 5PX2200iRT2UG2 includes eight IEC C13 outlets and supports extended battery modules for increased runtime. Communication options include USB, RS-232, and mini-terminal blocks for remote On/Off and output relay functions. The multilingual graphical LCD display provides real-time system information, and the UPS is ENERGY STAR® certified. With a compact 2U form factor, it is suitable for IT environments requiring reliable power protection.

Features

• High Efficiency (up to 98%) — Reduces energy consumption and cooling costs for cost-effective operation.
• Advanced Battery Management (ABM®) — Extends battery life by up to 50% and supports predictive maintenance.
• Multiple Outlets and Expandability — Includes eight IEC C13 outlets and supports external battery modules for longer runtime.
• Multilingual Graphical LCD Display — Offers real-time system information and easy configuration.

Specifications

• Model: 5PX2200iRT2UG2
• Rating: 2200VA
• Power Output: 2200W
• Input Voltage: 230V default (200/208/220/230/240V)
• Input Frequency: 50-60 Hz
• Output Voltage: 230 V (+6%/-10%)
• Dimensions (D x H x W): 603 x 85.5 x 438mm
• Weight: 28.2kg
• Battery Type: Sealed, lead-acid
• User Interface: LCD Display
• Expansion Slots: One slot for optional communication card
